Toyota Corolla (2014 – 2016) 10.1″ HD Touch-Screen Android Navigation System | Android 13 | GPS | BT | WiFi | Camera | CarPlay

$ 444.69

-

Express Worldwide Shipping

Newest version Android 10.0 !!!
Newest Generation Quad-Core Center Processor !!!
Built-in WiFi connectivity !!!
Retain original steering wheel control and stock camera !!!

Factory OEM Fit ! !
Built-in WIFI / Hotspot Compatible ! !
No Mounting Bracket or Wiring is required ! !
Retain Original Premium Sound System !
Retain Original Steering Wheel Control !
Built-in Wireless Apple CarPlay and Android Auto !

Full installation instruction and video is included to ensure a smooth installation !



During the promotion period, we do offer OBD2 adapter for free as a gift. *Limited time offer only*



Built-in Wireless Apple CarPlay and Android Auto

Does your car come with Original JBL Premium sound system? *

(Note: You can simply check that if there is any JBL mark on the original radio.)

Left-Hand Drive or Right-Hand Drive: *

(LHD: Left-hand drive) For the car with steering wheel on the Left.
(RHD: Right-hand drive) For the car with the steering wheel on the Right.
For example, US and Canada are LHD, UK and Australia are RHD.

Do you want to add a HD Wide-Angle CCD Reverse Camera?

Note: If your vehicle already come with “Original” reverse camera, it is not necessary to purchase a separate camera. The system already supported the original camera / original 360 camera.

Do you want to add Plastic Trim / Panel Removal Tool?

1 Pcs x Plastic Trim Panel Removal Tool (Can prevent from scratching the panel when removing the original dash.)

Do you want to add OBD II Bluetooth Adapter:

(Read diagnostic trouble codes, view freeze frame data & I/M readiness monitors, turn off the MIL/ Check Engine Light and view real-time sensor readings using third-party application.)

Description

All our products come with 1 year factory warranty. Extended warranty can be purchased separately.

This system is directly fit to the following models:

1: Toyota Corolla ( 2014 2015 2016 )

This system is equipped with the newest Octa-Core Center processor. It can ensure the smoothness and user experience of the system. This system is fully compatible with original steering wheel control, backup camera and sound system.

10.1″ HD Touch Screen  | Android 13.0 | 4GB + 64GB | WiFi | 4G LTE | Retain Original SWC & Camera
Built-in Wireless Apple CarPlay and Android Auto

Main Features

High-performance Quad Core Chipsets
HD 1024 x 640 Screen Resolution
Built-in WIFI Adapter
Built-in high-capacity iNAND – 4GB DDR4
Support ATHEROS ESP GPS module
Support High Speed USB Hub
Ultra Fast Start Time (1 – 2 sec Boot Time)
Multi-language OSD Menu Support: Russian/Turkish/Arabic/Italian/Portuguese…..etc
Original Backlight Illumination (OEM Style)
Picture in picture (PIP)
Support Original Steering Wheel Control
Highly Customizable Menu
Fast Internet Surfing
Wireless Apple CarPlay and Android Auto

Specification

Screen
10.1″ Digital HD Touch Screen – 1024*600 pixels
Image Brightness / Contrast / Color / Saturation Adjustable

Built in GPS System
Operation System: ANDROID 13
GPS Module: SiRF IV
GPS Processor: ATHEROS
DDR4 Memory:  4GB + 64GB
Navigation System: iGO8, TOMTOM, Route66, Sygic, Garmin…etc
GPS Menu OSD Languages: English/Chinese/German/French/Spanish/Dutch/Czech/Danish…etc
With Voice guidance (Male or Female)
Dual Zone Function
3D Map Supported

Bluetooth Compatibility
Version: V 5.0
Built-in Microphone in the control panel
External Microphone Jack Support
Support A2DP Bluetooth music function
Phone Book Support
Call Log Support (Dialed Call – Received call – Missed call)

4G LTE Connectivity
Support 4G LTE (Sim Card not included)

WiFi Connectivity
WiFi Hotspot Compatibility (Android or iPhone)
Auto-Detect Wifi Spot Connectivity

CarPlay and Android Auto Connectivity
Support Wireless Apple CarPlay
Support Wireless Android Auto

Radio
Built-in Radio Tuner ( 30 Preset Stations )
FM ( 3*6 ) 87.5-108MHz(North America), Increment: 0.05MHz
AM (2*6) 522-1620KHz, Increment: 9 KHz
In Radio mode, user can convert to Europe/ North America /Japan /OIRT radio frequency
Built-In RDS Radio Receiver (Display local radio channel name)

Input / Output
1 x Radio Antenna Input
2 x RCA Video Output ( Back Sight Video Input / AUX Video Input )
4 x RCA Audio FR/FL/RR/RL
Sub woofer output and AUX Audio R/L Input

Optional Function
DVB-T
SD Card with map ( Most recent map for Canada and US )
Rear View Camera Support
